Model nûmer.: MG4700S01-1
Merk: RisingLCD
Produktiviteit: 220k
Berteplak: Sina
Sertifikaat: CD/ROSH/ISO9001
De MG4700S01-1 hat in werjefte resolúsje fan 3840 (RGB) × 180, in aspektferhâlding fan> 3: 1 (breedte), en de piksels binne regele yn RGB-fertikale strepen. It displaygebiet grutte is 1192.3 × 55,89 (W × H) MM, en de eksterne grutte is 1208.12 × 72,59 (w × H) MM. De operaasjetemperatuer fan MG4700S01-1 is 0 ~ 50 ° C, en de opslachtemperatuer is -20 ~ 60 ° C.
[Service fan ien stop, wrâldwide operaasje en pleatslike stipe]
Rising Star biedt klanten mei ien-stop-winkelwein, en produkten binne stomme testen trochjûn om te soargjen dat de kwaliteit foldocht oan 'e spesifikaasjes. En bepale in heul ynformaasjeisearre kwaliteitsbehear System neffens ynternasjonale kwaliteitsnormen. Wrâldwide operaasjes, om perfekt technysk oerlis te leverjen, produktstipe en saaklike tsjinsten.
| brand | CSOT | Model name | MG4700S01-1 |
| size | 47inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 3840(RGB)×180 81PPI | Pixel configuration | RGB vertical bar |
| Display Area | 1192.3×55.89(H×V)mm | Surface treatment | Fog surface(Haze 25%) |
| Visual size | / | Contrast Ratio | 3000:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 1208.12×72.59 (H×V)mm |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | work environment | Storage temperature: -20 to 60 °C Operation Temperature: 0 to 50 °C |
| Signal interface | V-by-One 8 lane,51 pins,erminal | ||
| supply voltage | 12.0V (Typ.) |
