Shenzhen Risingstar Outdoor High Light LCD Co., Ltd
Shenzhen Risingstar Outdoor High Light LCD Co., Ltd
Betel wize:T/T,D/P,D/A,Paypal
Incoterm:FOB,CFR,CIF,EXW
Min. Oarder:1 Piece/Pieces
Transport:Ocean,Land,Air,Express
Haven:Shenzhen
Merk: Opkommende stjer
Size: 86-inches
Brightness: 500-nits
Produktiviteit: 150k
Transport: Ocean,Land,Air,Express
Berteplak: Sina
Sertifikaat: CE/ROSH/ISO9001
Haven: Shenzhen
Betel wize: T/T,D/P,D/A,Paypal
Incoterm: FOB,CFR,CIF,EXW
LD860DBN-UJA1, 86-inch floeibere kristalmodule fan TFT-LCD-technology, it is foarsjoen fan wreed achterljocht, ynklusyf late-stjoerprogramma efterljochtprogramma, gjin oanrekking.
De operearjende temperatuer is 0 ~ 50 ° C, en syn opslachtemperatuer is -20 ~ 60 ° C. De resolúsje fan LD860DBN-UJA1-werjaan fan LD860DBn-Uja1 is 3840 (RGB) × 600 is de Aspektferhâlding> 3: 1 (breedte), en it fertikale ferfarskingsrate FV is 60HZ. De piksels binne regele yn RGB fertikale strepen. Dit LCD-skerm is geskikt foar Digital-buordsjes, snije skerm-skerm.
F: Hoe kinne wy kwaliteit garandearje?
A: Altyd definitive ynspeksje foardat ferstjoering.
F: Is d'r in oare grutte of spesifikaasje kin kieze?
A: As jo ferskate grutte of spesifikaasjes nedich binne, sille wy it meast geskikte skema leverje neffens jo easken.
| brand | LG Display | Model name | LD860DBN-UJA1 |
| size | 86 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 3840(RGB)×600 45PPI | Pixel configuration | RGB vertical bar |
| Display Area | 2148.48×335.7(H×V)mm | Surface treatment | Fog surface(Haze 10%)，Hard coating (3H) |
| Visual size | 2149.5×336.7(H×V)mm | Contrast Ratio | 1100:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 2158.3×348.5×82.2(H×V×D)mm |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | Backlight type | WLED, 50K hours, including LED driver |
| Signal interface | 51 pins V-by-One 8 lane,erminal |
|
|
| work environment | Storage temperature: 0 to 50 °C Operation Temperature: -20to 60 °C |
|
|
Hot Tags: LD860DBN-UJA1 500NITS 86Inch Hot Sus TFT-LCD Panel, Sina, Cheap, Priis, finster LCD Skerm, Outdoot TV-paniel, 15 4UCH LCD-skerm, Helderste LCD, 15 4 Outdoor LCD-skerm , LCD-paniel, LCD-module, werjefte fan hege helderheid.
