Shenzhen Risingstar Outdoor High Light LCD Co., Ltd
Shenzhen Risingstar Outdoor High Light LCD Co., Ltd
Min. Oarder:1 Piece/Pieces
Merk: RisingLCD
Produktiviteit: 160K
Berteplak: Shen zhen
Sertifikaat: CE/ROSH/UL/ISO9001
| Panel Brand | RISINGSTAR | Panel Model | RS220WPM-NE10 |
| Panel Size | 22.0" | Panel Type | a-Si TFT-LCD , LCM |
| Resolution | 1680(RGB)×1050, WSXGA+, 90PPI | Pixel Format | RGB Vertical Stripe |
| Display Area | 473.76(W)×296.1(H) mm | Bezel Opening | 477.7(W)×300.1(H) mm |
| Outline Size | 493.7(W)×320.1(H) ×10.7(D) mm | Surface | Antiglare (Haze 25%), Hard coating(3H) |
| Brightness | 1000nit or customized | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 85/85/80/80 (Typ.)(CR≥10) | Display Mode | TN, Normally White, Transmissive |
| Display Colors | 16.7M 72% NTSC | Response Time | 1.5/3.5 (Typ.)(Tr/Td) |
| Frequency | 60Hz | Lamp Type | 3 strings WLED , 40K hours , Without Driver |
| Weight | 1.83Kgs (Typ.) | Input Voltage | 5.0V (Typ.) |
| Signal Interface | LVDS (2 ch, 8-bit) , 30 pins Connector | ||
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -25 ~ 60 °C | ||
RS220WPM-NE10 is in lade LCD-lade LCD-lade LCD-liif dy't LVD's ynterface stipet. It kin wurkje by temperatueren fan -20 ~ 70 ℃ en opslach temperatueren fariearje fan -30 ~ 80 ℃. RS220WPM-NE10 is in 1000 nits hege helderheid TFT LCD-module. It is geskikt foar yndustriële apparatuer, handheld apparaten, medyske apparatuer, outdoor en semi-outdoar omjouwing.
Funksjes
1. Hege helderheid, hege kontrast, snelle responstiid, multi-kleur-stipe, breed werjefte hoeke;
2. Nasjonale standert profesjonele produksjeline, miljoenen stoffrije omjouwing, it skermbody en LED-skerm fit;
3. Sertifikaasje, FCC, CE, CCC, UL, RoHS;
4. Profesjonele LED Backlight Technology.
5. Steklike struktuer, anty-eksterne ynfloed, metalen chassis.
1. Professional Outdoor High Leightness LCD Panel Fabrikant
2. Profesjonele LCD-skerm fan hege helderheid, kin 110 hege temperatuer wjerstean
3. Samsung, LG, Beo, Auo, Innolux Partnerbedriuwen
4. Jou jo profesjonele profesjonele technyske oerlis en begelieding
F: Kin ik in stekproef keapje foar myn bestelling?
A: Ja, nim dan gerêst kontakt mei ús op.
F: Hoe kinne wy kwaliteit garandearje?
A: Altyd definitive ynspeksje foardat ferstjoering;
F: Wat binne ús foardielen?
A: Low Price Hege kwaliteitsprodukten, yntiidske folchende ynformaasje.
F: Hoe lang is de garânsje?
A: Wy biede ien jier garânsje fan 'e datum fan levering.
F: Binne jo hannelsbedriuw of fabrikant?
A: Wy binne fabryk.
