Model nûmer.: LQ150X1LW96
De LQ150X1LW96 Display Resolúsje is 1024 (RGB) × 768 (XGA) is de Aspektferhâlding 4: 3 (breedte), en de piksels binne regele yn RGB-fertikale strepen. It displaygebiet grutte fan LQ150x1LW96 is 304.128 × 228.096 (w × H) mm is 307,4 × (w) is 326.5 (W) × 253,5 (H) × × 10.1 (D) mm. Matte finish, hurde coating (3h), netgewicht 950g (maks.)
De efterljochting nimt oannimt in ljochte boarne fan in rânstype, syn operearjende temperatuer is -20 ~ 70 ° C, en har opslachtemperatuer is -25 ~ 70 ° COP POLKSJE FOAR EINSTRIAL EN MEDISKE IEMPING.
| brand | Sharp | Model name | LQ150X1LW96 |
| size | 15inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768 [XGA] 85PPI | Pixel configuration | RGB vertical bar |
| Display Area | 304.128×228.096mm(H×V) | Surface treatment | Fog surface，Hard coating (3H) |
| Visual size | 307.2×231.1mm(H×V) | Contrast Ratio | 1500:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 326.5×253.5×10.1(H×V×D)mm |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) | work environment | Storage temperature: -25 to 70 °C Operation Temperature: -20 to 70 °C |
| Signal interface | LVDS (1 ch, 6/8-bit),erminal,20 pins | ||
| supply voltage | 3.3V (Typ.) |
F: Binne jo fabrikant (fabryk)?
A: Ja, wy binne. Ek OEM / ODM-tsjinst hjirbiet hjir Beskikber hjir om jo ideeën te dielen by ús. It is ús wille om de bêste oplossing foar jo te leverjen.
F: Kin ik in stekproef keapje foar myn bestelling?
A: Ja, nim dan gerêst kontakt mei ús op.
