Model nûmer.: LQ150X1LG96
De wurktemperatuer fan LQ150X1LG96 is 0 ~ 65 ° C, en de opslachtemperatuer is -30 ~ 70 ° C. It is geskikt foar yndustriële applikaasjes, bûtenkoppen, spultsjes. De oerflakbehandeling is mat, hurde coating (3h), en it netto gewicht fan it produkt is 950g (maks.). Yn termen fan efterljochting hat de side-type ljochtboarne in libbenspan fan 30k oeren.
De LQ150X1LVG97 Display Resolúsje is 1024 (RGB) × 768 (XGA), de Aspektferhâlding is 4: 3 (breedte), en de piksels binne regele yn RGB-fertikale strepen. It displaygebiet grutte fan LQ150X1LG96 is 304.128 × 228.096 (w × H) mm, is de sichtbere grutte is 326.5 (W) × 253,5 (H) × × 10.1 (D) mm.
| brand | Sharp | Model name | LQ150X1LG96 |
| size | 15inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768 [XGA] 85PPI | Pixel configuration | RGB vertical bar |
| Display Area | 304.128×228.096mm(H×V) | Surface treatment | Fog surface，Hard coating (3H) |
| Visual size | 307.2×231.1mm(H×V) | Contrast Ratio | 800:1 (Typ.) (TM) |
| Brightness(cd/m²) | 1050cd/m²(Typ.)or customized | Outline dimension | 326.5×253.5×10.1 mm(H×V×D) |
| Viewing Angle | 80/80/60/80 (Typ.)(CR≥10) | work environment | Storage temperature: -30 to 70 °C Operation Temperature: 0 to 65 °C |
| Signal interface | LVDS (1 ch, 6/8-bit),erminal,20 pins |
|
|
| supply voltage | 3.3V (Typ.) |
|
|
Hot Tags: 15Inch skerpe lq150x1Lg9,ft febrewaris, Sina, Cheap, Priis, uttoap-advertinsjes, âlderdom, bûten, LCD-skerm UK, tinne skerm foar TV, werjaan skerm UK, werjaan skerm UK, werjaan skerm Outdoor LCD Panel 2500 Nits , LCD-paniel, LCD-module, werjefte fan hege helderheid.
