Model nûmer.: TDA150-005V01
TDA150-005V01 A-SI TFT-LCD 15-inch floeibere kristalmodule, typyske funksjes binne wite LED-efterljochting, ynklusyf LED-sjauffeur, matde oerflak. Syn operearjende temperatuer is -20 ~ 70 ° C, en syn opslachtemperatuer is -30 ~ 80 ° C. De werjaan Resolúsje is 1600 (RGB) × 1200 (UXGA), en de piksels binne regele yn RGB-fertikale strepen. It displaygebiet grutte is 304.8 × 228,6 (w × H) mm, en de eksterne diminsje is 317.4 (W) × 242 (h) mm.
It is in ljochte boarne fan in râne-type mei in libbensspan fan 30k oeren, ynklusyf LED-sjauffeurs. TDA150-005V01 oannimt LVDS (2 Ch, 8-bit) sinjaalynterface, yn totaal 40 Pins, dy't ferbûn binne troch terminals, en de stasjonspanning is 3.3v (typ.).
F: Wa binne wy?
A: R-Star is ûntstien út Shenzhen, Sina, wy binne in profesjonele fabrikant fan High End LCD, wy kinne leverje fan 10.1 nei 120 inch HIFT LCD-modules, ynklusyf 20 erfarne ynlanner. It bedriuw hat ISO9001 / ISO14001 / CCC / CE / FCC trochjûn / Rohs / UL en oare sertifikaasjes, hat in hege nivo r & d-platfoarm wurden fan in protte bedriuwen fan wrâldklasse. Markten cover-Aazje, de dekken Amearika, Afrika, Midden-Easten, Jeropa, Sintraal en Súd-Amearika en Oseaan en Oseaan. Wy leauwe dat as jo ús in kâns jouwe om te tsjinjen, sille wy jo fertroude leveransier yn Sina jaan yn Sina.
F: Binne jo fabrikant (fabryk)?
A: Ja, wy binne. Ek OEM / ODM-tsjinst hjirbiet hjir Beskikber hjir om jo ideeën te dielen by ús. It is ús wille om de bêste oplossing foar jo te leverjen.
F: Hoe kinne wy kwaliteit garandearje?
A: Altyd definitive ynspeksje foardat ferstjoering.
| brand | BOE | Model name | TDA150-005V01 |
| size | 15 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1600(RGB)×1200 [UXGA] 133PPI | Pixel configuration | RGB vertical bar |
| Display Area | 304.8×228.6mm (H×V) | Surface treatment | Fog surface(Haze 25%)，Hard coating (3H) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Min.)(CR≥10) | Outline dimension | 317.4 × 242 mm (H×V) |
| Signal interface | LVDS (2 ch, 8-bit) ,erminal, 40 pins |
|
|
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
|
|
Deselde grutte en model binne as folgjend:
| brand | BOE | Model name | RT150X0M-N10 |
| size | 15 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768, XGA, 85PPI | Pixel configuration | RGB vertical bar |
| Display Area | 304.8×228.6mm (H×V) | Surface treatment | Fog surface(Haze 25%)，Hard coating (3H) |
| Brightness(cd/m²) | 1100cd/m²(Typ.)or customized | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 80/80/80/80 (Min.)(CR≥10) | Outline dimension | 326.5×253.5(H×V) |
| Signal interface | LVDS (1 ch, 8-bit) ,erminal, 20 pins |
|
|
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
|
|
| brand | BOE | Model name | DV150X0M-N16 |
| size | 15 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768, XGA, 85PPI | Pixel configuration | RGB vertical bar |
| Display Area | 304.128×228.096(H×V) mm | Surface treatment | Fog surface(Haze 25%)，Hard coating (3H) |
| Brightness(cd/m²) | 600cd/m²(Typ.)or customized | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89(Min.)(CR≥10) | Outline dimension | 326.5×253.5×9.7mm(H×V×D) |
| Signal interface | 20 pins LVDS (1 ch, 8-bit) , erminal |
|
|
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
|
|
| brand | BOE | Model name | RV150U0M-N00 |
| size | 15 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1600(RGB)×1200 [UXGA] 133PPI | Pixel configuration | RGB vertical bar |
| Display Area | 304.8 × 228.6 mm (H×V) | Surface treatment | Fog surface(Haze 25%)，Hard coating (3H) |
| Visual size | 307.2 × 231 mm (H×V) | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 317.4×242 mm(H×V×D) |
| Viewing Angle | 85/85/85/85(Min.)(CR≥10) |
|
|
| Signal interface | LVDS (2 ch, 8-bit),40 pins, erminal |
|
|
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
|
|
