UV215FHM-N10 is in 21,5-inch floeibere kristalmodule mei A-SI TFT-LCD-resolúsje is 1920 (FHB) × 1080 (FHD) is 16: 9 (breedte: Hichte), en de Pixel) Advertinsjes RGB is yn fertikale strepen regele. It displaygebiet grutte is 476,64 × 268.11 (w × H) mm, de sichtbere grutte is 479.8 (w × H) mm is 495.6 (W) × 292.2 (H) × 11,2 (D) MM.
Behandele as Matte (Haze 25%), Hard Coating (3h), de wurktemperatuer is -20 ~ 80 ° C, en syn opslachtemperatuer is -30 ~ 85 ° C. Foar digitale buordsjes. Edge-type ljochtboarne, it tsjinstfeest fan 'e ljochtboarne is 30k oeren, mei LVDS (2 CH, 8-bit) Signal-ynterface, yn totaal 30 Pins .
F: Is d'r in oare grutte of spesifikaasje kin kieze?
A: As jo ferskate grutte of spesifikaasjes nedich binne, sille wy it meast geskikte skema leverje neffens jo easken.
F: Wat is jo foarferkeap en nei-ferkeap tsjinst?
A: Yn termen fan foarferkeaptsjinst hawwe wy in profesjonele ferkeapteam en technysk om jo fragen te beantwurdzjen binnen 24 oeren. Wat ynstalleare ynstallearje, kinne wy ynstallearje, brûke en ferfange skansearre modulen.
F: Hoe kinne wy in goede saaklike relaasje mei lange termyn ûnderhâlde?
A: Wy behâlde goede kwaliteit en kompetitive prizen om te soargjen dat klanten foardiel binne; Wy respektearje elke klant en behannelje se as freonen. Makket net út wêr't se komme fan, wy dogge oprjocht saken dwaan mei har en meitsje freonen.
| brand | BOE | Model name | UV215FHM-N10 |
| size | 21.5 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1920(RGB)×1080 FHD 102PPI | Pixel configuration | RGB vertical bar |
| Display Area | 476.64×268.11(H×V)mm | Surface treatment | Fog surface(Haze 25%)，Hard coating (3H) |
| Visual size | / | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 495.6×292.2×11.2mm(H×V×D) |
| Viewing Angle | 89/89/89/89(Typ.)(CR≥10) | ||
| Signal interface | 30 pins LVDS (2 ch, 8-bit),erminal | ||
| work environment | Storage temperature: -30 to 85 °C Operation Temperature: -20 to 80 °C |
Parameters fan itselde grutte model
| brand | BOE | Model name | DV215FHM-R01 |
| size | 21.5 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1920(RGB)×1080 FHD 102PPI | Pixel configuration | RGB vertical bar |
| Display Area | 476.64×268.11(H×V)mm | Surface treatment | Fog surface(Haze 25%)，Hard coating (3H) |
| Open zone | 479.8×271.3(H×V)mm | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 495.6×292.2×11.2mm(H×V×D) |
| Viewing Angle | 89/89/89/89(Typ.)(CR≥10) | ||
| Signal interface | 30 pins LVDS (2 ch, 8-bit),erminal | ||
| work environment | Storage temperature: -20 to 85 °C Operation Temperature: -20 to 85 °C |
