Min. Oarder:1 Piece/Pieces
Model nûmer.: BA104S01-100
BA104S01-100 is in 10.4-inch LCD-module produkt lansearre troch Boe Technology Group Co., Ltd. (Boe) mei help fan A-SI TFT-LCD-technology. It is foarsjoen fan wreaune efterljocht, gjin efterljochting ride en gjin oanrekking. BA104S01-100 toant in resolúsje fan 800 (RGB) × 600 (SVGA), in aspektferhâlding fan 4: 3 (hichte), en de piksels binne regele yn RGB-fertikale strips, neffens de produktspesifikaasje nr. Rev .1 Utbrocht troch Boe op 12 desimber 2014. It display gebiet is 211.2 × 158,4 (breedte, fisuele grutte) MM is 215.0 × Hichte) MM, ferskininggrutte is 236 × 176,9 (breedte × hichte is) × 5.9 (dikte) mm, is oerflakte behanneling is dúdlik, produkt netto gewicht is 288g (typ.). Backlight Dit produkt brûkt in 6S6P-wreaune ljocht foare-yngongspoar (boppe), it libben fan 'e ljochtboarne is 50k oeren, gjin efterljochtstasjon. BA104S01-100 Adoptart LVDS (1 Ch, 6/8-bit) sinjaalynterface, yn totaal 20 Pins, oannimt terminalferbining, DRIVE-skermspanning is 3,3V (Typ.). It typyske fertikale ferfarskingsrate FV is 60HZ. It wurket op -20 ° C oant 70 ° C en winkels op -30 ° C oant 80 ° C. Dit model wurdt oanrikkemandearre foar gebrûk yn yndustriële en medyske ôfbylding fanwege har wite LED-efterljochting, mear dan 50.000 oeren fan it libben, terminal flip, 6/8 bits fan opsjoneel grize skaal, en oare funksjes.
| brand | BOE | Model name | BA104S01-100 |
| size | 10.4 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 800(RGB)×600 [SVGA] 96PPI | Pixel configuration | RGB vertical bar |
| Display Area | 211.2×158.4 mm (H×V) | Surface treatment | Clear |
| Visual size | 215.0×162.0 mm (H×V) | Contrast Ratio | 800:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 236×176.9×5.9 mm (H×V×D) |
| Viewing Angle | 70/70/60/70 (Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 6/8-bit) ,erminal, 20 pins | ||
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
It folgjende binne deselde modellen en parameters
| brand | BOE | Model name | AV104X0M-N10 |
| size | 10.4 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768 (XGA) 123PPI | Pixel configuration | RGB vertical bar |
| Display Area | 210.4 × 157.8 (H×V) mm | Surface treatment | / |
| Visual size | 215.4 × 161.8 (H×V) mm | Contrast Ratio | 1100:1 (Typ.) (TM) |
| Brightness(cd/m²) | 600cd/m²(Typ.)or customized | Outline dimension | 230 × 180.2(H×V) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 6/8-bit) ,erminal, 20 pins | ||
| work environment | Storage temperature: -40 to 95 °C Operation Temperature: -30 to 85 °C |
| brand | BOE | Model name | TDA104-001V02 |
| size | 10.4 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768 (XGA) 123PPI | Pixel configuration | RGB vertical bar |
| Display Area | 210.4 × 157.8 (H×V) mm | Surface treatment | / |
| Visual size | / | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Brightness(cd/m²) | 900cd/m²(Typ.)or customized | Outline dimension | 235×173×10.5mm(H×V×D) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 8-bit) ,erminal, 20 pins | ||
| work environment | Storage temperature: -55 to 85 °C Operation Temperature: -40 to 80 °C |
